PFR-100系列開關式PFR-100LPFR-100M可編程直流電源產品詳細規格
快速選型
| 型號 | 電流 | 電壓 | 功率 | 前后面板輸出 | 標配接口 |
| PFR-100L | 10A | 50V | 100W | YES | USB/RS232 |
| PFR-100M | 2A | 250V | 100W | YES | USB/RS232 |
| 詳細規格 | ||
| 型號 | PFR-100L | PFR-100M |
| 輸出容量 | ||
| 額定電壓 | 50V | 250V |
| 額定電流 | 10A | 2A |
| 額定功率 | 100W | 100W |
| 定電壓模式(CV) | ||
| 負載調節率 (*2) | 10mV | 33mV |
| 電源調節率 (*1) | 3mV | 5mV |
| Regulation(CC) | ||
| 負載調節率 (*9) | 10mA | 3.2mA |
| 電源調節率 (*1) | 8mA | 1.2mA |
| 輸出漣波及雜訊(*3) | ||
| Vp-p (*4) | 50mV | 150mV |
| Vr.m.s.(*5) | 4mV | 15mV |
| A r.m.s. | 10mA | 2mA |
| 程控度 | ||
| 電壓0.1% of setting + | 40mV | 200mV |
| 電流0.2% of setting + | 20mA | 2mA |
| 量測度 | ||
| 電壓0.1% of reading + | 40mV | 200mV |
| 電流0.2% of reading + | 20mA | 2mA |
| 反應時間 | ||
| 上升時間 (*6)Rated load | 50ms | 200ms |
| 下降時間 (*7)Rated load | 100ms | 300ms |
| No load | 500ms | 3000ms |
| 負載變動回復時間 (*8) | 1.5ms | 2ms |
| 程控解析度 | ||
| 電壓 | 2mV | 10mV |
| 電流 | 1mA | 0.1mA |
| 量測解析度 | ||
| 電壓 | 2mV | 10mV |
| 電流 | 1mA | 0.1mA |
| 保護 | ||
| 過電壓 (OVP)Setting range | 5 - 55V | 5 - 275V |
| 過電流 (OCP)Setting range | 1~11A | 0.2 - 2.2A |
| 低電壓限制 (UVL)Setting range | 0 - 52.5VV | 0 - 52.5V |
| 過溫度保護(OTP)Operation | Turn the output off. | |
| 低輸入電源保護 (AC-FAIL)Operation | Turn the output off. | |
| 電源限制(POWER LIMIT)Operation | Turn the output off. | |
| 前面板顯示, 4 位 | ||
| 電壓0.1% of reading + | 40mV | 200mV |
| 電流0.2% of reading + | 20mA | 2mA |
| 環境條件 | ||
| 操作溫度 | 0?C to 40?C | |
| 儲存溫度 | -20?C to 70?C | |
| 操作濕度 | 20% to 80% RH; No condensation | |
| 儲存濕度 | 20% to 85% RH; No condensation | |
| 溫度系數(30分鐘暖機后) | ||
| 電壓 | 100ppm/℃ | |
| 電流 | 200ppm/℃ | |
| 其它 | ||
| 類比控制 | Yes | |
| 界面 | USB, RS-232/ RS-485; Factory option: LAN/ GPIB | |
| 電源輸入 | 85 ~ 265VAC, 47~63Hz, single pahse | |
| 尺寸& 重量 | 70(W) × 124(H) × 300(D) mm; Approx. 3kg | |
